Protective Cage

The newly developed digital HD chimney inspection camera SK7 delivers razor-sharp images in HD quality.The power supply is provided by advanced lithium-ion battery technology, ensuring long operating time.The inspection camera is a compact and user-friendly device, ideal for inspections from the roof. Its large 7" color monitor displays sharp images. Photos and videos can be easily stored on an SD card and played back on-site. The display also shows time and date, and the digital meter counter simplifies length measurement.A sunshield makes inspections easier even in bright daylight. It is magnetically attached around the carrying handle and serves as display protection during transport.On the back, there is a protected storage compartment for the camera head. Additionally, the SK7 can be connected to a camera reel.The package includes a carrying harness, ensuring optimal handling on the roof—keeping both hands free at all times!The HD rotating ball camera is controlled via a joystick. It has an infinite rotation range and a 90° tilt range. The camera module is protected behind a glass cover and surrounded by a bright SMD lighting ring with a reflector for optimal illumination.The camera module automatically adjusts the focus, requiring no manual adjustments during inspections.The new HD camera module generates high-resolution images.A reel connection (optional accessory) can be easily attached via a bayonet lock, enabling inspections from bottom to top as well.Technical Data – SK7 HD:Digital meter count displayed on the LCDVoltage indicator (unit: %) displayed on the LCDPhoto & video storage on SD cardRotatable cable reel with 20 m cableCable connection: 8-pin connector7" color LCD TFT displayResolution: 1280 x 720 pixelsLithium-ion batteryBattery runtime: approx. 4 hoursCharging time: approx. 3.5 hoursDimensions: 307 x 285 x 200 mm (W x H x D)Weight: approx. 4.31 kgTechnical Data – HD Rotating Ball Camera:Camera module resolution: 1280 x 720 pixelsColor CCD camera moduleLight sensitivity: 0.8 LuxTilt range: 90°Rotation range: Endless (no stop)Bright lighting with 15 SMDsConnector: 8-pin plugHead diameter: 56 mm, Length: 152 mmWeight: approx. 326 gScope of Delivery:HD Chimney Inspection Camera SK7HD Rotating Ball Camera4 GB SD card20 m cableSunshieldCarrying harnessPower supply unit

Rotary Ball Camera Pro The Rotary Ball Camera is controlled by 4 control buttons. An all-encompassing view of 360° pan and 90° tilt. The Camera Module is protected behind glass and is surrounded by a SMD-lightning-ring, including a reflector which will provide an optimal illumination. The Camera Head can be easily connected through the bayonet connecting system. - High precision camera lens (92°) with automatic iris control - Color-CCD-Camera Module - Lightning: 15 SMDs - Photosensitivity: 0,8 Lux - Diameter: 49 mm - Length: 153 mm - Weight: approx. 312 g

The newly developed HD color monitor is the optimal companion in a measuring case or backpack due to its small size and lightweight design. The integrated lithium-ion battery provides approximately 2.5 hours of operation. Photos and videos can be stored on the SD card.The new HD pan-tilt camera is controlled using 4 Navigation buttons. It has a rotation range of 360° and a tilt range of 90°. The camera module is protected behind a glass pane and is surrounded by an illumination ring with a reflector, which ensures optimal lighting.The camera module handles focusing automatically. No adjustments are necessary during the inspection.Magnets on the back of the protective case allow the monitor to be attached to a boiler, enabling hands-free operation during inspections.Technical Specifications:Image and video storage on SD cardLCD TFT display 5" 720p: 102 x 73 mmLED voltage indicator in the displayDimensions: 135 x 220 x 39 mm (WxHxD)Weight approx. 1100gTechnical data HD pan-tilt camera:Color CCD camera module: HD resolution 1280 x 720 pixelsLight sensitivity 0.8 LuxTilt range: 90°Rotation range: endless without stopBright illumination through 15 SMDsConnector: 8-pinHead diameter 56 mm, length 152 mmWeight approx. 326 gScope of delivery:HD monitor FM5 ProHD rotating spherical cameraPower supply/charger30 m metered cableProtective case with magnetSD card
