RESS-Leakage Tester DP 5 - Set - consisting of:

The newly developed digital HD chimney inspection camera SK7 delivers razor-sharp images in HD quality.The power supply is provided by advanced lithium-ion battery technology, ensuring long operating time.The inspection camera is a compact and user-friendly device, ideal for inspections from the roof. Its large 7" color monitor displays sharp images. Photos and videos can be easily stored on an SD card and played back on-site. The display also shows time and date, and the digital meter counter simplifies length measurement.A sunshield makes inspections easier even in bright daylight. It is magnetically attached around the carrying handle and serves as display protection during transport.On the back, there is a protected storage compartment for the camera head. Additionally, the SK7 can be connected to a camera reel.The package includes a carrying harness, ensuring optimal handling on the roof—keeping both hands free at all times!The HD rotating ball camera is controlled via a joystick. It has an infinite rotation range and a 90° tilt range. The camera module is protected behind a glass cover and surrounded by a bright SMD lighting ring with a reflector for optimal illumination.The camera module automatically adjusts the focus, requiring no manual adjustments during inspections.The new HD camera module generates high-resolution images.A reel connection (optional accessory) can be easily attached via a bayonet lock, enabling inspections from bottom to top as well.Technical Data – SK7 HD:Digital meter count displayed on the LCDVoltage indicator (unit: %) displayed on the LCDPhoto & video storage on SD cardRotatable cable reel with 20 m cableCable connection: 8-pin connector7" color LCD TFT displayResolution: 1280 x 720 pixelsLithium-ion batteryBattery runtime: approx. 4 hoursCharging time: approx. 3.5 hoursDimensions: 307 x 285 x 200 mm (W x H x D)Weight: approx. 4.31 kgTechnical Data – HD Rotating Ball Camera:Camera module resolution: 1280 x 720 pixelsColor CCD camera moduleLight sensitivity: 0.8 LuxTilt range: 90°Rotation range: Endless (no stop)Bright lighting with 15 SMDsConnector: 8-pin plugHead diameter: 56 mm, Length: 152 mmWeight: approx. 326 gScope of Delivery:HD Chimney Inspection Camera SK7HD Rotating Ball Camera4 GB SD card20 m cableSunshieldCarrying harnessPower supply unit

HD-FM7 Set for Exhaust Pipes - consisting of:HD Mini Camera ReelIdeal for exhaust ducts – highly flexible yet stable, suitable for use as a handheld or coupling reel. The reel features a digital meter counter that is displayed on the screen.- Fiberglass camera rod, 20 m long and Ø 5 mm - Extremely flexible and strong enough to push the camera head far up - Basket diameter only 31 cm - Transport lock - Needle bearing - Freewheel brake - 8-pin connector** on the handle and 12-pin connector** at the rod end Scope of Delivery:- HD color monitor FM7- HD miniature camera MK29- HD mini camera reel, 20 m with digital meter counter - 2 m connection cable- Protective bag with magnet - Power adapter/charger

Backpack 3.0 The main part closes with a magnetic lock instead of a zipper. - Material: durable and water-repellent Cordura - Left part: 2 pockets, smaller with flap, larger with MOLLE SYSTEM and fastening straps incl. 3 removable Velcro straps - On the right: a large side pocket with MOLLE SYSTEM and 2 slide-in compartments - Adjustable division incl. a sheet metal plate for measuring instruments - Front pocket padded and suitable for notebook or tablet - Padded backpack straps with reflective stripes - Padded carrier handle with Velcro strap - Reflective stripes - Overall dimension: 44 x 54 x 32 cm (BxHxT) - Weight: 4,4 kg (Delivery does not content pictured accessories) Art.- no. 5300-J

The DP 200 leak testing device is a fully automatic measuring instrument designed to determine the tightness of exhaust lines operating under pressure up to 200 Pa. The device has been tested and approved by TÜV according to the guidelines for the suitability testing of leak testing devices. Its lightweight and compact design, along with battery operation, ensures a particularly handy and uncomplicated use. Measurements can easily be carried out even from the roof, saving time and effort.Continuous MonitoringDuring the measurement, the values can be continuously monitored and read on the display. The DP 200 calculates the permissible leak rate for the respective pipe dimensions entered. The display shows the maximum pressure at which the system can be operated without exceeding the permissible leak rate. If the system is not in order, an extended measurement procedure can be performed to determine the test pressure when the exhaust line precisely reaches the permissible leak rate.Infrared Interface for Data TransferAn infrared interface allows the transfer of measurement data to an infrared printer (optional accessory).SpecificationsDimensions: 145 mm x 235 mm x 65 mm (WxLxH)Weight: approximately 1580 gDelivery ContentsLeak Testing Device DP 200Printer InterfaceChargerCarrying StrapSealing Bladder with Device Hose NW 50-150 mmSealing Bladder with Valve NW 50-150 mm2 Pump Balls

The gas leak detector "GasPen digital" is applicable for locating gas leaks on indoor and outdoor areas. With the movable sensor head you can also measure in unapproachable locations. The gas sensor fitted in the sensor head, reacts to Methane (CH4, natural gas). The measuring range starts with 100 ppm up to 10.000 ppm (1,0 Vol%). The results can be heard through an acoustic signal or/and 5 LEDs, which are assigned to particular gas concentration. - Dimension: 25 x 45 x 136 mm - Flexible piece 160 mm - Weight: 145 g (incl. Battery) - Operating time: 12 hours - Battery LED Delivery contents GasPen light, plastic case, 2 x 1,5 V Battery, control certificate, manual

The DP5 leak test device is used to check exhaust systems at 200, 1,500, and 5,000 Pa (classes P1, M1, H1). Another application is to verify sufficient combustion air supply according to TRGI standards.Applications:Simplified Procedure: Measurement with the gas appliance in operation.Detailed Procedure: Measurement with defined air extraction using the DP5.You can watch an application video [here].Advantages:Battery operation enables measurements from the roof.Mains operation for uninterrupted work.Now with storage for exhaust line tests.Lightweight and handy device.Increased utility by testing air yield according to TRGI.Easy operation via a large 7" touch screen.Simple language selection: German, English, Italian, Polish, Hungarian, Turkish.Technical Data:Pressure Measurement Range 1: 0 to 5,000 PaPressure Measurement Range 2: 0 to 125 PaAir Flow Rate: 0 to 60 m³/hBattery: 24V with 3.2AhMains Operation: 230VWeight: approx. 3.8 kgDimensions: 22x31x8.5 cm (WxHxD)LCD Color Touch Display 7"USB and IRDA InterfaceTÜV certifiedScope of Delivery:DP5 Leak Test DeviceIntegrated BatteryPower/Charger Adapter
